Facilities

Our lab has several mass spectrometers from different vendors including Thermo Fisher, Agilent, Bruker, and PerkinElmer. We have also developed two ion soft landing instruments for ion deposition and purification on the surface.

Q-Exactive HF-X Orbitrap Mass Spectrometer

Agilent Ion Mobility Q-TOF Instrument

Agilent Single-Quadrupole ICP-MS

Bruker timsTOF Pro 2

LC-MS System (LTQ, Thermo).

Q-Exactive HF-X Orbitrap Mass Spectrometer

Ion soft-landing instrument. Dual polarity high flux ion soft-landing instrument.

Ion soft-landing instrument equipped with a collision cell. Dual polarity high flux ion soft-landing instrument.

Nano-DESI cart setup on Agilent IM Q-TOF. nano-DESI stage set-up on Q-Exactive HF-X. Closer look at the nano-DESI probe set-up. Zoomed in image of nano-DESI probes scanning the sample.

Images left to right:

Nano-DESI cart setup on Agilent IM Q-TOF;
Nano-DESI stage set-up on Q-Exactive HF-X;
Closer look at the nano-DESI probe set-up with (1) primary capillary, (2) secondary capillary, (3) shear force probe, (4) sample, (5) mass spectrometer;
Zoomed in image of nano-DESI probes scanning the sample
